FH70/ 150/ 200 LED

Aluminium, steel and glass: sturdy and completely recyclable

A single polyvalent fixture for use either as a projector or a louvre, combining design, sturdiness and superlative technical lighting features. The dual possibility of symmetrical and asymmetrical light diffusion is embodied in the same product and is achieved thanks to a louvre with divisible modules. A single fixture to achieve total coverage in outdoor lighting, solving the most varied technical lighting problems thanks to an innovative optical project based on efficiency and glare control. The small dimensions of the housing contrast with the depth of the beam of light which has no limits of use.

Technical Specifications

Specifications Spotlights/Projectors
Installations Wall, Suspension, Floor
Body Polyester powder coated die-cast aluminium RAL 7040
Optic Sheet metal with parabolic development in anti-iridescent, mirror finished, anodised aluminium. Symmetrical Asymmetrical
Screen Prismatic toughened glass 4 mm
Equivalent power 70, 150, 200 W
Light source LED
LED Power 39, 68, 86 W
Temperature 4000 K
LED Flux 7000, 12000, 16350 lm
Device Flux 6300, 10000, 13000 lm
Efficiency 140, 137, 132 lm/W
Energy class A++
Degree of protection IP66
Dimensions Length: 323 mm | Width: 116 mm | Height: 319 mm
